Uses of the machine :
- Pulveriser machine grinds gram dal (pulses) flour of papad, turmeric harad behada.
- Big Pulveriser machine can grind chemical mineral, coal, bauxite, gypsum ayurvedic, medicinal plants (jadi buti), soap stone, calcite and leather chips.
Information of the machine :
- Pulveriser machine has a gear box. The gear box helps in feeding the materials to grinding chamber through hopper.
- Material grind in this machine is first collected in the bag, and the dust is collected in the dust collector.
- This machine grinds the material from 100 to 300 meshes.
- This machine is manufactured with M.S. heavy plate material.
- The capacity & mesh are approximately only and depends upon the nature of the material to be pulcerized.
- There are 9 models of this machine.
Specifications :
| H.P.(1440 rpm) |
3-5 |
5-7.5 |
10-15 |
15-20 |
25-30 |
40-50 |
50-60 |
80-100 |
100-125 |
| Grindling chamber size (inches) |
10 |
12 |
16 |
20 |
25 |
32 |
32 super |
42 |
42 super |
| Hammer |
8 |
8 |
8 |
8 |
8 |
8 |
16 |
16 |
16 |
| RPM of machine |
2800 |
2800 |
2300-2500 |
2300-2500 |
1800-2000 |
1800-2000 |
1800 |
1800 |
1800 |
c
a
p
a
c
i
t
y
(Kg/hr) |
Besan |
30-40 |
60-75 |
140-160 |
200-250 |
300-400 |
600-700 |
700-900 |
1000-1200 |
1200-1500 |
| Mineral |
50-75 |
75-100 |
150-200 |
250-300 |
400-500 |
700-900 |
900-1100 |
1100-1400 |
1400-1700 |
| Ayurvedic Jadi-buti |
8-10 |
20-25 |
50-60 |
80-100 |
130-150 |
250-300 |
300-350 |
400-500 |
500-600 |
| Fine mess upto |
100-300 |
100-300 |
100-300 |
100-300 |
100-300 |
100-300 |
100-300 |
100-300 |
100-300 |
| Space required |
10x10x10 |
10x10x10 |
10x10x10 |
10x10x11 |
10x10x13 |
12x10x16 |
19x10x18 |
20x12x20 |
20x12x20 |
Shivraj Agro Industries Reserves All The Rights Regarding Desgining Machines And Machinery Plant And Technical Changes.
